What Is Trigonometry? The Mathematics of Circles Hiding in Triangles

Trigonometry is not about triangles. It's about circles.

Here's the unlock: every triangle is a frozen snapshot of circular motion. When a point rotates around a center, its vertical position traces out sine. Its horizontal position traces out cosine. The triangle is just what you see when you stop the rotation and draw lines.

This is why trigonometry appears everywhere that things oscillate, rotate, or repeat. Pendulums. Sound waves. Planetary orbits. AC current. Anything that cycles does trigonometry.

The triangle is the disguise. The circle is the truth.

The Standard Story (And Why It Misleads)

You're probably taught that trigonometry is about ratios in right triangles. "Sine is opposite over hypotenuse. Cosine is adjacent over hypotenuse."

This is technically true but deeply unhelpful.

It makes trigonometry seem like a collection of tricks for measuring triangles. It hides the actual subject — which is the mathematics of rotation and oscillation.

The triangle ratios are a consequence of the circle, not the foundation.

The Circle First

Imagine a point P moving counterclockwise around a circle of radius 1 centered at the origin.

At any moment, P has coordinates (x, y).

x is the horizontal distance from center. This is cosine of the angle.

y is the vertical distance from center. This is sine of the angle.

That's it. Sine and cosine are just the coordinates of a rotating point.

When the point is at the rightmost position (3 o'clock), the angle is 0°. The coordinates are (1, 0). So cos(0°) = 1 and sin(0°) = 0.

When the point reaches the top (12 o'clock), the angle is 90°. The coordinates are (0, 1). So cos(90°) = 0 and sin(90°) = 1.

Where Triangles Come From

Draw a line from the point P down to the x-axis. You get a right triangle.

• The hypotenuse is the radius (length 1)
• The horizontal leg is x (cosine)
• The vertical leg is y (sine)

The triangle is inside the circle. The ratios "opposite over hypotenuse" work because the hypotenuse is the radius, and the legs are the coordinates.

You don't need triangles to understand trig. Triangles are just a way of seeing the coordinates frozen at a moment.

Why "Opposite Over Hypotenuse" Works

In a right triangle with angle θ:

• The opposite side is across from θ
• The adjacent side is next to θ (not the hypotenuse)
• The hypotenuse is the longest side (opposite the right angle)

If you put this triangle inside a unit circle (radius = 1), the hypotenuse is the radius.

So opposite/hypotenuse = y/1 = y = sin θ

And adjacent/hypotenuse = x/1 = x = cos θ

The ratio definitions aren't the foundation — they're a consequence of putting the triangle inside a circle with radius 1.

The Unit Circle Makes It Simple

The unit circle has radius 1 centered at the origin.

On a unit circle:

• cos θ is the x-coordinate of the point at angle θ
• sin θ is the y-coordinate of the point at angle θ

No ratios needed. Just coordinates.

For any other circle with radius r:

• x = r cos θ
• y = r sin θ

Scale the coordinates by the radius. That's all.

Why Trig Shows Up Everywhere

Anything that goes in circles uses trigonometry:

• Wheels rotating
• Planets orbiting
• Gears turning

Anything that oscillates back and forth uses trigonometry:

• Pendulums swinging
• Sound waves vibrating
• Springs bouncing

Why? Because oscillation is circular motion viewed from the side.

A point going around a circle, viewed edge-on, looks like it's bouncing up and down. That vertical motion is sine.

This is why every wave can be described with sines and cosines. Waves are rotation viewed from one direction.

The Trig Functions

The three main trig functions are:

Sine (sin θ): The y-coordinate. How high is the rotating point?

Cosine (cos θ): The x-coordinate. How far right is the rotating point?

Tangent (tan θ): The ratio sin θ / cos θ. The slope of the line from origin to the point.

Three more functions are their reciprocals:

Cosecant (csc θ): 1/sin θ Secant (sec θ): 1/cos θ Cotangent (cot θ): 1/tan θ = cos θ / sin θ

Angles: Measuring Rotation

An angle measures how much you've rotated.

Degrees: A full circle is 360°. This comes from ancient Babylon (approximately days in a year, highly divisible).

Radians: A full circle is 2π. This is the more natural unit — 1 radian is when the arc length equals the radius.

Conversion: 180° = π radians

Mathematicians prefer radians because they make calculus clean. The derivative of sin(x) is cos(x) only when x is in radians.

The Fundamental Relationship

Since (cos θ, sin θ) is a point on the unit circle:

cos²θ + sin²θ = 1

This is the Pythagorean theorem. The horizontal and vertical distances from the origin, squared and added, equal the radius squared (which is 1).

This identity isn't something to memorize — it's geometrically obvious once you see the circle.

Why This Matters

Physics runs on trigonometry because physics runs on waves and rotation.

Light is electromagnetic waves — described by sine and cosine.

Sound is pressure waves — sine and cosine.

Quantum mechanics uses complex exponentials, which are sine and cosine in disguise (Euler's formula: e^(iθ) = cos θ + i sin θ).

When you learn trigonometry, you're learning the mathematics of everything that repeats. And most of nature repeats.

The Core Insight

Trigonometry is circle mathematics wearing a triangle disguise.

Sine and cosine are coordinates of rotation. Tangent is the slope of the radius. The ratios in right triangles work because the triangle is embedded in a circle.

Once you see the circle, trigonometry stops being about memorizing formulas. It becomes about understanding the geometry of rotation — which turns out to be the geometry of waves, oscillations, and cycles.

The universe runs on circles. Trigonometry is the language they speak.

Part 1 of the Trigonometry series.
